BLTX: Bluetooth Keyboard with Center Touchpad

Rugged Bluetooth keyboard with adjustable backlighting and a touchpad

SKU: KBA-BLTX-BT-US

Custom Keyboard Solutions

TG3 will bring your custom input solutions to life. Get Started

83 keys
Black
Bluetooth BLE (pairing instructions)
Low profile docking station / charging station
Lithium ion battery pack
Backlighting rated for life of the product (200,000 hr LEDs)
Low cost, ultra rugged keyboard
Low profile with ergonomic design and feel
Tactile full travel key switches
Embedded multimedia functionality
IP65 rated
Chemical resistant engineered plastic resin housing and keycaps
Splash-proof touchpad with 2 sealed mouse buttons
10 million actuations per key
Optional logo
Multiple standard mounting options
Rubber option available

Compliant

FCC
CE
RoHS

Electrical Specifications

Voltage: +5Vdc from data cord
Radiated immunity: 20 Volts / meter
Backlight dimming includes 8 levels of intensity
Controlled by Fn + 0 – 7 keys or Fn + Up / Down cursor keys
X/Y position resolution: 500 points / inch (20 points max)

Data Sheet

KBA-BLTX-BT-US Data Sheet (PDF)

Instructions

Cleaning Instructions and Approved Cleaners (PDF)
